HOME > PRODUCT > 웨이프&약품류

DOW / Advanced Electronics Resin(Photo BCB) * CYCLOTENE 4000 series



◆특징 ▷Negative acting ▷Sensitive to G-line, I-line and broad band radiation ▷Solvent development ▷Excellent film retention ▷Excellent planarization ◆사양

DW-4044-01

4022-25

Cured Thickness：0.8 ∼1.8μm, 장기 보관(12-18달):-15℃, 중기 보간(1-2달)：4℃

견적 문의

DW-4044-02

4022-35

Cured Thickness：2.5 ∼5.0μm, 장기 보관(12-18달):-15℃, 중기 보간(1-2달)：4℃

견적 문의

DW-4044-03

4022-40

Cured Thickness：3.5 ∼4.5μm

견적 문의

DOW / ANC Cyclotene Adhesion Promoter



◆특징 ▷Adhesion Promoter is a pre-mixed solution that requires no further dilution. ▷The interfaces between CYCLO Advanced Electrorics Resins and underlying layers in a device (e.g., metal or inorganics) usually require a surface treatment or preparation to ensure reliable bonding. ◆사양

DW-4046-01

AP3000

수입금지 품목

견적 문의

DW-4046-02

AP8000

구성：Propylene glycol monomethyl ether, 포장단위：3.5kg/pk

견적 문의

DOW / ANC Cyclotene Developer Solvent



◆특징 ▷DS3000 is a solvent for development of photosensitive films, using a batch immersion process. ▷DS2100 is a solvent for development of photosensitive films, using a puddle or spray process. ◆사양 ▷Component - DS2100 : Dipropylene glycol dimethyl ether/ Isopar L - DS3000 : Triisopropylbenzene

DW-4045-01

DS2100

Static puddle and spray Method, 포장단위：3.5kg/pk

견적 문의

DW-4045-02

DS3000

Immersion and batch spin and rinse Method, 포장단위：5kg/pk

견적 문의

DOW / ANC Cyclotene Rinse Solvent



◆특징 ▷Rinse Solvent has been found to work well in thin film applications and is compatible with most surfaces and equipment materials ◆사양 ▷1,3,5-trimethylbenzene (mesitylene)

DW-4048-01

T1100

구성：1,3,5-trimethylbenzene (mesitylene), 포장단위：3.5kg/pk

견적 문의

DOW / Cyclotene Stripper



◆사양 ▷Amber to dark brown/Black liquid with hydrocarbon like odor ▷An organic solvent with a strong organic acid. Protective equipment is needed ▷Effective stripe time is 30 minutes or less, making it attractive as a batch process.

DW-4047-01

Primary Stripper A

포장단위：4L/bt

견적 문의
